The objectivity of the measurement is essential when working in a shared environment, where the presetting operation is carried out by multiple people.

Objectivity is important, as is the precision of the measurement.  For this reason, it is necessary to have an efficient and high-performance tool.

The E46B presetter series have been designed and built with superior quality components, dedicated to this specific application: presetting, measuring and inspecting a tool.

For over 30 years we have been using granite for the base and the column: in fact, it allows our presetters to have a high degree of dimensional stability, guaranteeing precision and repeatability of measurements.

E46BP was born from the need to have a tool presetter capable of semi-autonomously carrying out the positioning and measurement operations of the cutting edges, in order to further reduce the risk of errors and automate the presetting operation.



POSITIONED: AXIS AND MEASUREMENT AUTOMATION

INTUITIVE: NO COMPLICATIONS, TAILOR-MADE FOR YOU

UNIQUE: A PRESETTER WITH EXCEPTIONAL QUALITIES



How does the new automatic axis positioning system work?

The operation is very simple and intuitive: once the tool has been identified, the theoretical diameter and height values and the tolerances have been entered, the presetter is able to position itself and automatically carry out the measurement operation of the maximum values of X and Z, with a 360° rotation of the spindle.

The measurement can be repeated as many times as desired by simply "recalling" the tool to be measured. The user will only have to wait for the machine to complete the operation.

E46BP can be equipped with the new Automatic Tool Recognition system.

GENERAL FEATURES

  • Measuring range: max diameter 400 mm (radius 200 mm); max height 600 mm
  • Base and column in natural granite: max linearity error 8 µm/m
  • Steel base with 3 fixed and 1 adjustable feet
  • Linear guideways (2 X axis, 1 Z axis) with double recirculating ball bearings slides
  • Pneumatic axis movement unlock
  • Motorized axis movement
  • Manual gross movement
  • Motorized fine adjustment
  • ECN AS371 certified optical scales (resolution 1µm)
  • Vertical TFT 15,6" Full HD Touch Screen Monitor
  • Keyboard and mouse
  • Overall dimensions: L = 1179 mm, H = 1935 mm, D = 568 mm
  • Net weight: ~ 230 kg
X Axis Measure (Diameter) Z Axis Measure (Length) Natural Granite Base & Column Interchangeable Spindle Cartridge C Axis Display Spindle Body and Spindle Cartridge Interchangeable Spindle Max. Run-Out Error Automatic Rotation of the Spindle Spindle Index in four Angular Positions (0º, -90º, -180º, -270º) Spindle Rotation Brake Spindle Identification System (NFC recognition) Clamping System Tool Inspection Function/Capability Elbo Controlli NIKKEN Triple Camera System (Cutting Edge Inspection) Main Camera System Resolution Main Camera System Measuring Range (C-MOS Sensor Framed Image Area) Secondary 'Twin' Camera System Measuring Ranges (Framed Image Area) Main Camera Magnification Secondary 'Twin' Camera System Magnifications Elbo Controlli NIKKEN Certified Optical Scale Axes Resolution Elbo Controlli NIKKEN GS371 Certified 'Natural Granite' Optical Scale Axes Resolution Touch Screen System (Operator Interface) Keyboard and Mouse Electronics/Processor Firmware/Operating System Data Storage Elbo Controlli NIKKEN Tool Management Software Tool Set Management and Post Processor Universal Generation DXF File Import and Creation Balluff Read/Write Ready (Balluff Hardware Required)? Elbo Controlli NIKKEN TiD Ready? Elbo Controlli NIKKEN TP32 Ready? Elbo Controlli NIKKEN IS 'Integrated Solution' with Twin Screen and Dual OS Option Ready?
E46BP Tool Presetter
