NIKKEN Multi-Spindle CNC Rotary Tables are a great solution to enhance capacity and process.

With the ability to multi-load parts, the CNC180-2W is ideal for manufacturing small items and mass-producing parts.

The inclusion of the multiple spindles for the construction of the CNC180-2W make absolutely no compromise to performance and, just like the rest of the NIKKEN CNC Rotary Table range, promises to enhance productivity while maintaining unrivalled high precision, high rigidity and durability.

The CNC180-2W is also available with a high-speed motor that can quickly deliver a substantial return on investment.

The rotary table can be supplied with a range of motors and controllers to meet your specific requirements - see the downloads section for more information or contact us to learn more.

CNC180-2W Rotary Table
CNC180-2W Rotary Table Technical Diagram

Nikken Rotary Table Catalogue – 2019

(PDF - 62.5 MB)

CNC180-2W
Face Plate Diameter[Ømm] 180
Table Range/Type MULTI-SPINDLE
Standard Motor Orientation (Left Hand Option Available for Right Hand Tables) RIGHT
Diameter of Spindle Hole [Ømm H7] 60
Number of Spindles x Pitch [mm] 2 x 250
Centre Height [mm] 175
Width of T-Slot [mm] 12
Clamping System AIR
Clamping Torque [Nm] 303
Table Inertia at Motor Shaft [Kg m2 x 103] 0.12
Servo Motor [min1] αiF4·3000
Min. Increment [Degrees] 0.001
Rotation Speed [min1] 33.3
Total Reduction Ratio 1/90
Indexing Accuracy [sec] ±20
Indexing Accuracy Ultra Precision [sec] N/A
Net Weight [Kg] 115
Max. Vertical Work Load on Table [Kg] 100
Max. Horizontal Work Load on Table [Kg] 200
Max. Horizontal Thrust Load on the Table [N] 18000
Strength of Worm Wheel Without Brake (Against Dynamic Cutting Thrust) [FxL Nm] 542
Max. Thrust Load on the Table [FxL Nm] 690
Guideline of Max. Unbalancing Load (Vertical with Support) [Nm] N/A
Max. Work Inertia [Kg m2] 0.5
Driving Torque [Nm] 72
