The NIKKEN CNC321 uses hydraulic clamping for a clamping torque of 1760Nm with an average of 22.2RPM.

This difference between the CNC321 and the CNC321B is the motor is mounted to the backside of the rotary table rather than the left or right, making it perfect for machines that don't have ample space for the Y axis.

The CNCZ321 comes with a high-speed motor as standard that can quickly deliver a substantial return on investment.

The rotary table can be supplied with a range of motors and controllers to meet your specific requirements - see the downloads section for more information or contact us to learn more.

CNC(Z)321B Rotary Table
CNC(Z)321B Rotary Table Technical Diagram
CNC(Z)321B
Face Plate Diameter[Ømm] 320
Table Range/Type STANDARD
Standard Motor Orientation (Left Hand Option Available for Right Hand Tables) REAR
Diameter of Spindle Hole [Ømm H7] 105
Number of Spindles x Pitch [mm] 1
Centre Height [mm] 230
Width of T-Slot [mm] 12
Clamping System HYD
Clamping Torque [Nm] 1760
Table Inertia at Motor Shaft [Kg m2 x 103] 7
Servo Motor [min1] αiF12·2000
Min. Increment [Degrees] 0.001
Rotation Speed [min1] 22.2 (44.4)
Total Reduction Ratio 1/90 (1/45)
Indexing Accuracy [sec] 15
Indexing Accuracy Ultra Precision [sec] N/A
Net Weight [Kg] 240
Max. Vertical Work Load on Table [Kg] 250
Max. Horizontal Work Load on Table [Kg] N/A
Max. Horizontal Thrust Load on the Table [N] 53100
Strength of Worm Wheel Without Brake (Against Dynamic Cutting Thrust) [FxL Nm] 2648
Max. Thrust Load on the Table [FxL Nm] 3840
Guideline of Max. Unbalancing Load (Vertical with Support) [Nm] 100
Max. Work Inertia [Kg m2] 6.4 (3.2)
Driving Torque [Nm] 432 (345)
