E46CA Tool Presetter

Today, companies are looking for technological solutions that adapt to their specific needs to remain competitive in the market.

In an industry where automation becomes a constant request a presetter with that provided an autofocus capability becomes a necessity.

The AUTOFOCUS function allows tools to be measured automatically, without the operator intervening manually. This mode is recommended for those who need to carry out measurements on multi-edged tools which would be very long if carried out manually and, above all, which reduces the risk of human error to a minimum.

Once the tool has been blocked, the operator will simply have to choose what type of measurement he wants to carry out (single cutting edge or multi-cutting edge) and what to measure (X, Z or both axes) and start the measurement cycle. Without having to enter the number of cutting edges to measure or any theoretical value, the software will automatically start the cycle and end it once the 360° rotation has been carried out.

• AUTOMATIC: AUTOFOCUS FUNCTION = NO MEASUREMENT ERROR
• INNOVATIVE: ITS PATENTED SYSTEM MAKES THE PRODUCT UNIQUE
• RELIABLE: NATURAL GRANITE MAKES THE DIFFERENCE

It is very important for us to patent the innovative technological solutions that we study and develop for our products- Through patents we are able to enhance our products which reflect Elbo Controlli NIKKEN’s cutting-edge level of technology and proposed solutions.

For this reason, the "Research and Development" department is constantly engaged in the study of unique solutions, which sets us apart from all the others.

Elbo Controlli NIKKEN has developed a system that adapts the peripheral rotation speed of the tool based on the maximum diameter to be measured: the constant peripheral speed avoids the introduction of errors, whether you are measuring a 2 mm diameter tool or a 200 mm one.

E46CA can be equipped with the new Automatic Tool Recognition system.

GENERAL FEATURES

• Measuring range: max diameter 400 mm (radius 200 mm); max height 600 mm
• Base and column in natural granite: max linearity error 8 µm/m
• Steel base with 3 fixed and 1 adjustable feet
• Linear guideways (2 X axis, 1 Z axis) with double recirculating ball bearings slides
• Pneumatic axis movement unlock
• Manual gross movement
• Manual fine adjustment
• ECN AS371 certified optical scales (resolution 1µm)
• Vertical TFT 21,5" Full HD Touch Screen Monitor
• Keyboard and mouse
• Label printer side support
• Spindles side support (1 for 2 spindles)
• Overall dimensions: L = 1179 mm, H = 1935 mm, D = 568 mm
• Net weight: ~ 230 kg
