E46B Tool Presetter

The new E46B presetter machine allows you to optimize the machine tools setup, reducing downtime in your workshop.

The E46B presetter series have been designed and built with superior quality components, dedicated to this specific application: presetting, measuring and inspecting a tool.

The base and column are made of natural granite. For over 30 years we have been using granite for the base and the column: in fact, it allows our presetters to have a high degree of dimensional stability, guaranteeing precision and repeatability of measurements. When granite makes the difference!

The new AS371 optical scales model allow for high and precise performance. The development of this essential component is given by forty years of experience in the field of measurement in the mechanical sector.

We have dedicated a lot of attention to the development of the spindle holders, a fundamental element for a successful measurement. All our spindle holders are interchangeable, avoiding the use of adapters so as not to introduce coupling errors.

The latest electronics generation have allowed the performance of the presetter to be significantly increased. The quality of the measurement is essential for us.

E46B is equipped with a 15.6" vertical capacitive touch screen monitor, positioned vertically for better viewing of both data and measurement functions.

INNOVATIVE: NEW TECHNOLOGY AT YOUR SERVICE

SIMPLE: EASE OF USE IS THE WINNING WEAPON

RELIABLE: DESIGNED TO GIVE YOU THE BEST

Why complicate your life with complex software? The new user interface derives from smartphone technology, making the software more “familiar”. Seeing is believing.

Smartphone-type usability has allowed us to develop easy and intuitive software: scroll the pages from left to right and vice versa with a simple movement of your fingers on the screen, hold down an icon to open the submenu, manage and customize the monitor spaces according to your needs. Limits are made to be overcome!

The new presetter generation is waiting for you! Elbo Controlli NIKKEN: presetting experience for over 40 years!

GENERAL FEATURES

• Measuring range: max diameter 400 mm (radius 200 mm); max height 600 mm
• Base and column in natural granite: max linearity error 8 µm/m
• Steel base with 3 fixed and 1 adjustable feet
• Linear guideways (2 X axis, 1 Z axis) with double recirculating ball bearings slides
• Pneumatic axis movement unlock
• Manual gross movement
• Manual fine adjustment
• ECN AS371 certified optical scales (resolution 1µm)
• Vertical TFT 15,6" Full HD Touch Screen Monitor
• Overall dimensions: L = 1136 mm, H = 1935 mm, D = 568 mm
• Net weight: ~ 230 kg
